UPS AON3000-2 ONLINE USB + RS232 BLACK ADVICE
₪3368.2
1 מוצר/ים הוספ/ו לסל
מידע נוסף על UPS AON3000-2 ONLINE USB + RS232 BLACK ADVICE
Features:
• Output power factor 0.9
• Double conversion on line design
• Automatic battery management
• USB-RS232 connectors
• SNMP card/ dry contact card (optional)
• External battery connector
• 600 Joule surge protection- Exclusive
• Wide input voltage (120 Vac – 300Vac) at 230vac
• Microprocessor control optimizes reliability
• Bypass
• Frequency converter mode
• ECO mode
• Generator compatible
Specifications:
Specifications:
| PHASE | Single phase with ground |
| CAPACITY | 3000 VA / 2700 W |
| INPUT | |
| Nominal Voltage | 100/110/115/120/127VAC or 200/208/220/230/240VAC |
| Voltage Range Low Line Transfer | 60 VAC / 70 VAC / 80 VAC / 90 VAC ± 5 % or 120 VAC / 140 VAC / 160 VAC / 180 VAC ± 5 % |
| ( based on load percentage0% - 60 % / 60 % - 70 % / 70 - 80 % / 80 % - 100%) | |
| Low Line Comeback | 70 VAC / 80 VAC / 90 VAC / 100 VAC ± 5 % or 135 VAC / 155 VAC / 175 VAC / 195 VAC ± 5 % |
| ( based on load percentage 0% - 60 % / 60 % - 70 % / 70 - 80 % / 80 % - 100%) | |
| High Line Transfer | 140VAC / 150 VAC ± 5 % or 280 VAC / 300 VAC ± 5 % |
| ( based on load percentage0 - 80 % / 80 % - 100%) | |
| High Line Comeback | 135VAC / 140 VAC ± 5 % or 270VAC / 280 VAC ± 5 % |
| ( based on load percentage0 - 80 % / 80 % - 100%) | |
| Frequency Range | 40Hz ~ 70 Hz |
| Power Factor | >= 0.99 @ Nominal Voltage (100% load) |
| OUTPUT | |
| Output Voltage | 100/110/115/120/127VAC or 200/208/220/230/240VAC |
| Voltage Regulation | ± 1% |
| Frequency Range (Synchronized Range) | 47~ 53 Hz or 57 ~ 63 Hz |
| Frequency Range (Batt. Mode) | 50 Hz or 60Hz ± 0.5% |
| Current Crest Ratio | 3:1 |
| Harmonic Distortion | <= 3 % THD (Linear Load) |
| <= 6 % THD (Non-linear Load) | |
| Transfer Time AC to DC | Zero |
| Inverter to Bypass | 4 ms (Typical) |
| Waveform (Batt. Mode) | Pure Sinewave |
| EFFICIENCY | |
| To AC Mode | 90,00% |
| To Battery Mode | 88,00% |
| BATTERY | |
| Standard Model Battery Type | 12 V / 9 AH |
| Typical Recharge Time | 4 hours recover to 90% capacity |
| Charging Current (max.) | 1.0 A |
| Charging Voltage | 82.1VDC ± 1% |
| INDICATORS | |
| LCD | Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators |
| ALARM | |
| Battery Mode | Sounding every 4 seconds |
| Low Battery | Sounding every second |
| Overload | Sounding twice every second |
| Fault | Continuously sounding |
| PHYSICAL | |
| Standard Model Dimension, D x W x H | 421 x 190 x 318 |
| (mm) | |
| Net Weight (kgs) | 27.6 |
| ENVIRONMENT | |
| Humidity | 20-90 % RH @ 0- 40В°C (non-condensing) |
| Noise Level | Less than 50dBA @ 1 Meter |
| MANAGEMENT | |
| Optional SNMP | Power management from SNMP manager and web browser |
| Smart RS-232/USB | Supports Windows 2000/2003/XP/Vista/2008/7/8/10, Linux, Unix, and MAC according software list |
| Standard | CE,EN62040-1,EN62040-2 |
- מק"ט מוצר: 11270
- יצרן: Advice
- זמינות: במלאי
- מצב המוצר: חדש
- סוג מכירה: רגיל
- סוג מוצר: רגיל
- הובלה: 3 days
- אחריות: 2 years
